Where the oppositely angled teeth meet in the middle of a herringbone gear, the alignment may be such that tooth tip meets tooth tip, or the alignment may be staggered, so that tooth tip meets tooth trough. Precision herringbone gears are more difficult to manufacture than equivalent spur or helical gears and consequently are more expensive. Because of this herringbone gears were an important step in the introduction of the steam turbine to marine propulsion. This means that herringbone gears can be used in torque gearboxes without requiring a substantial thrust bearing. Their advantage over the helical gears is that the side-thrust of one half is balanced by that of the other half.

helical gear design in catia pdf

Like helical gears, they have the advantage of transferring power smoothly because more than two teeth will be in mesh at any moment in time. The gear set’s teeth may be manufactured so that tooth-tip aligns with the opposite tooth-tip, or so tooth-tip aligns with the opposite gear’s tooth trough.

helical gear design in catia pdf

However, due to their tooth structure, herringbone gears nullify the axial thrust typical of helical gears. Like helical gears multiple teeth are engaged during rotation, distributing the work load and offering quiet operation. Herringbone gears mate via the use of smooth, precisely manufactured V-shaped teeth. Unlike helical gears they do not produce an additional axial load. From the top the helical grooves of this gear looks like letter V.

helical gear design in catia pdf

1 Herringbone GearĪ herringbone gear, a specific type of double helical gear, is a special type of gear which is a side to side (not face to face) combination of two helical gears of opposite hands. The unique tooth structure of a herringbone gear consists of two adjoining, opposite helixes that appear in the shape of the letter ‘V’. Herringbone gears, also called double helical gears, are gear sets designed to transmit power through parallel or, less commonly, perpendicular axes.
